Features:

• 9 10/100/1000Mbps RJ45 ports, 1 Gigabit SFP port
• With 8 PoE+ ports, transfers data and power on one single cable
• Works with IEEE 802.3af/at compliant PDs and expands office network
• 802.1p/DSCP QoS enables smooth latency-sensitive traffic
• High PoE power budget with up to 30W for each PoE port and 63W for all PoE ports
• Easy to use, with no configuration and installation needed

Dedicated 8-Port PoE+ Switch for Wide Range of Applications with 63 W PoE Budget

Port 1-8 of the switch support Power over Ethernet (PoE) function. It provides a simple way to expand a wired network by transferring power and data over a single Ethernet cable. With a total power budget of 63W, up to 30W per port, TL-SG1210P has a wide range of applications, such as surveillance, conference calls, WiFi coverage. It is fully compatible with wireless Access Points (APs), IP-Caremas, and IP-Phones.

Premium hardware design

High Performance with Two Gigabit Uplink Ports

Dedicated 1x gigabit uplink RJ45 port and 1x gigabit SFP slot ensure smooth streaming. The two uplink ports can be used to connect the router/switch and NVR equipment.

Powered-Device Detection

Automatically detects and provides required power for your PoE devices, and protects your non-PoE equipment from being damaged.

Advanced Software Functions

Fluent Online Experience

Administrators can use QoS to designate the priority of traffic. For example, prioritize your cameras or IP-phones to ensure that voice and video applications remain clear and lag-free.

Traffic Optimization for IPTV

IGMP Snooping optimizes multimedia traffic delivery to ensure a better network experience especially for applications like IPTV.

Specifications:

HARDWARE FEATURES

• Interface: 8 PoE+ 10/100/1000Mbps RJ45 Ports 1 10/100/1000Mbps RJ45 Port 1 Gigabit SFP Slot
• Network Media: 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 100BASE-TX: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 1000BASE-X MMF, SMF
• Fan Quantity: Fanless
• Physical Security Lock: Yes
• Power Supply: External Power Adapter(Output: 53.5VDC / 1.31A)
• Packet Forwarding Rate: 14.88 Mpps
• PoE+ Ports(RJ45): Standard: 802.3at/802.3af compliant PoE Ports: Port1- Port 8 PoE Power Budget: 63W
• Mac Address Table: 4K
• Jumbo Frame: 16 KB
• Switching Capacity: 20 Gbps
• Dimensions ( W x D x H ): 209 × 126 × 26 mm
• Max Power Consumption: 7.11 W (220/50Hz. no PD connected) 78.13 W (220/50Hz. with 63W PD connected)
• Max Heat Dissipation: 24.25 BTU/h (no PD connected) 266.42 BTU/h (with 63W PD connected)

SOFTWARE FEATURES

• Advanced Features: Compatible With IEEE 802.3af/at Compliant PDs EEE802.3x Flow Control 802.1p/DSCP QoS IGMP Snooping
• Transmission Method: Store-And-Forward

OTHERS

• Certification: CE, FCC, RoHS
• Package Contents: TL-SG1210P, Power Adapter, Installation Guide
• Environment: Operating Temperature: 0°C~40°C (32°F~104°F) Storage Temperature: -40°C~70°C (-40°F~158°F) Operating Humidity: 10% ~ 90% non-condensing Storage Humidity: 5%~90% non-condensing
