Garmin ChartPlotter Combo ECHOMAP UHD2 52cv 5" Display with GT20-TM Transducer, Sonar Support, Vivid Color Palettes, Bundle Your Transducer, Add Charts, Wireless Networking WW, w/GT20 xdcr 010-02589-01

WHY TALK TO A LOCAL WHEN YOU CAN FISH LIKE ONE?

They say locals know best. But anyone who says that hasn’t fished with the ECHOMAP UHD2 5″ and 7″ chartplotters with clear, crisp sonar and mapping.

  The bright 5″ or 7″ keyed display is made for convenience.

  Get double the views¹ with Garmin CHIRP traditional and ClearVü scanning sonars.

  What’s under the water looks even better with high-contrast vivid colour palettes.

  Wi-Fi^® connectivity² between compatible chartplotters makes it easy to share info.

  Enjoy No. 1 in mapping³ with our Garmin Navionics+ and Garmin Navionics Vision+.

SONAR SUPPORT

With crisp, clear traditional sonar and brilliant ClearVü sonar, the fish will have nowhere to hide.

VIVID COLOR PALETTES

High-contrast vivid scanning sonar color palettes make it easier than ever to distinguish targets and structure.

BUNDLE YOUR TRANSDUCER

Your ECHOMAP UHD2 device supports a variety of Garmin transducers for two types of sonar: Garmin traditional and ClearVü scanning sonars.

ADD CHARTS

Know the waters you’re in as if you grew up fishing them by using optional Garmin Navionics+^™ and Garmin Navionics Vision+^™ marine cartography.

WIRELESS NETWORKING

If you have another compatible ECHOMAP UHD2 chartplotter on your boat, the 5″ and 7″ models can wirelessly share information — such as sonar, waypoints and routes — with them.

Specifications:

General:

• Dimension: 7.4" x 4.8" x 2.4" (18.8 x 12.2 x 6.2 cm)
• Weight: 1.1 lbs (0.5 kg)
• Waterproof: IPX7
• Display Type: WVGA, IPS
• Display Size: 4.3" x 2.6" (10.9 x 6.6 cm)
• Display Resolution: 800 x 480 pixels
• Mounting Options: Bail or Flush

Maps & Memory:

• Accepts Data Cards: 1 microSD™ card; 32 GB maximum size
• Waypoints: 5,000
• Track Points: 50,000
• Tracks: 50 saved tracks
• Navigation Routes: 100

Sensors:

• GPS
• Galileo
• Has Built-in Receiver
• Receiver: 5 Hz
• Supports WAAS

Built-in Maps:

• Built-in Auto Guidance+: Yes (downloadable via ActiveCaptain app)
• Garmin Navionics+ Inland & Coastal: Yes (see additional)
• Optional Map Support
• Bluechart G3
• Bluechart G3 Vision
• Garmin Navionics+™
• Garmin Navionics Vision+™
• Garmin Quickdraw Contours

Chartplotter Features:

• ActiveCaptain Mobile Planning Compatible

Electrical Features:

• Power Input: 9 to 18 VDC
• Typical Current Draw at 12 VDC: 1 A
• Maximum Current Draw at 12 VDC: 1.5 A
• Maximum Power Usage at 10 VDC: 18W

Sonar Features & Specifications:

• Displays Sonar
• Power Output: 500W
• Traditional Sonar (Dual Frequency/Beam): Built-in (single channel CHIRP, 70/83/200 kHz, L, M, H CHIRP)
• ClearVü: Built-in 260/455/800 kHz

Connections:

• 4-pin Transducer Ports: 1
• Garmin Wi-Fi Network (Local Connection)

Additional Garmin Navionics+ (Inland and Coastal):

• 55cv Canada
• 55cv Australia/New Zealand

Garmin Navionics+ (Coastal):

• 54cv U.S.
• 55cv U.K./Ireland

Garmin Navionics+ (Inland):

• 53cv U.S. Lakes

Tide Tables:

• 53cv, 54cv, 55cv, 73cv, 74cv, 75cv
