Intelligent and efficient network power protection from entry level to scalable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs, and other network devices.
Includes: Documentation CD, Smart UPS signaling RS-232 cable, USB cable

Features:

Cold-start capable Provides temporary battery power when the utility power is out.
Energy meter Provides actual kilowatt hours of usage for energy-conscious users.
Green mode Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.
High online efficiency Reduces utility costs and generates less heat.
Intuitive LCD interface Provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy-to-use navigation keys.
Predictive replacement battery date Dynamically provides the month and year when battery replacement is recommended to aid in long-term maintenance planning.
Pure sine wave output on the battery Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.
Sequenced network shutdown and reboot Customized network shutdown and reboot sequence of connected servers and UPSs.
Single switched outlet group Single outlet group that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off, and non-critical load shedding.
SmartSlot Customize UPS capabilities with management cards.
StruxureWare Central compatible Enables centralized management via StruxureWare Central.
Temperature-compensated battery charging Prolongs battery life by regulating the charge voltage according to battery temperature.

Smart-UPS Features & Benefits

Safety

Safety-agency approved Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.

Availability

Automatic restart of loads after UPS shutdown Automatically starts up the connected equipment upon the return of utility power.
Disconnected battery notification Warns when a battery is not available to provide backup power.
Automatic self-test Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Boost and Trim Automatic Voltage Regulation (AVR) Gives higher application availability by correcting low and high voltage conditions without using the battery (not available on all models).
Intelligent battery management Maximizes battery performance, life, and reliability through intelligent, precision charging.
Power conditioning Protects connected loads from surges, spikes, lightning, and other power disturbances.
Temperature-compensated battery charging Prolongs battery life by regulating the charge voltage according to battery temperature.

Marketing Features

Avoids costly power problems by keeping your IT equipment and data safe and available Network-grade power conditioning protects from damaging surges and disruptive noise. Solid state automatic voltage regulation boosts low input voltage up to 30% and trims high voltage up to 12% without battery operation. Reliable battery backup capacity to power through outages or gracefully shutdown systems
Peace of mind that comes with full equipment compatibility and reliability of a leader Provides pure sine wave output which is recommended by server manufacturers using active power factor corrected (PFC) power supplies. Safety agency-tested and approved means that you can deploy Smart-UPS with confidence that they meet or exceed the industry’s most rigorous standards.
Smarter productivity with the ability to tailor to your specific application needs Intuitive LCD interface provides clear information with the ability to configure the UPS locally with easy-to-use navigation keys. Over 15 different programmable settings including switched outlet group control allow for application-specific settings, thresholds, and notifications.
Save time with easy and convenient remote accessibility Network manageable via serial, USB, or optional ethernet. Includes Powerchute® Business Edition Software for convenient monitoring and control, safe operating system shutdown, and innovative energy management capabilities.
Low operating and maintenance costs with high efficiency, proven reliability and intelligent battery management Patented green operating mode achieves efficiencies of over 97%. Smart-ups was the first network UPS to be Energy Star certified. Intelligent battery management, pioneered by APC, maximizes battery performance and life through intelligent, precision temperature-compensated charging. Dynamic battery replacement date indicator and automatic self-tests insure battery reliability and warn in advance of needing replacement. Convenient, easy-to-connect, hot-swappable battery modules provide battery replacement without powering down. Designed and manufactured by APC for over 23 years, Smart-UPS is the world’s most trusted network UPS with over 25 million units sold.

Manageability

USB connectivity Provides management of the UPS via a USB port (not available on all models).
Serial connectivity Provides management of the UPS via a serial port.
Disconnected battery notification Warns when a battery is not available to provide backup power.
LED status indicators Quickly understand unit and power status with visual indicators.
Audible alarms Actively let you know if the unit is on battery, if the battery is low, or if there is an overload condition.
Network manageable Provides remote power management of the UPS over the network.

Marketing Features

Smarter productivity with the ability to tailor to your specific application needs Intuitive LCD interface provides clear information with the ability to configure the UPS locally with easy-to-use navigation keys. Over 15 different programmable settings including switched outlet group control allow for application-specific settings, thresholds, and notifications.
Save time with easy and convenient remote accessibility Network manageable via serial, USB, or optional ethernet. Includes Powerchute® Business Edition Software for convenient monitoring and control, safe operating system shutdown, and innovative energy management capabilities.
Low operating and maintenance costs with high efficiency, proven reliability and intelligent battery management Patented green operating mode achieves efficiencies of over 97%. Smart-ups was the first network UPS to be Energy Star certified. Intelligent battery management, pioneered by APC, maximizes battery performance and life through intelligent, precision temperature-compensated charging. Dynamic battery replacement date indicator and automatic self-tests ensure battery reliability and warn in advance of needing replacement. Convenient, easy-to-connect, hot-swappable battery modules provide battery replacement without powering down. Designed and manufactured by APC for over 23 years, Smart-UPS is the world’s most trusted network UPS with over 25 million units sold.
Avoids costly power problems by keeping your IT equipment and data safe and available Network-grade power conditioning protects from damaging surges and disruptive noise. Solid state automatic voltage regulation boosts low input voltage up to 30% and trims high voltage up to 12% without battery operation. Reliable battery backup capacity to power through outages or gracefully shutdown systems
Peace of mind that comes with full equipment compatibility and reliability of a leader Provides pure sine wave output which is recommended by server manufacturers using active power factor corrected (PFC) power supplies. Safety agency-tested and approved means that you can deploy Smart-UPS with confidence that they meet or exceed the industry’s most rigorous standards.

Availability

Disconnected battery notification Warns when a battery is not available to provide backup power.
Temperature-compensated battery charging Prolongs battery life by regulating the charge voltage according to battery temperature.
Automatic restart of loads after UPS shutdown Automatically starts up the connected equipment upon the return of utility power.
Boost and Trim Automatic Voltage Regulation (AVR) Gives higher application availability by correcting low and high voltage conditions without using the battery (not available on all models).
Automatic self-test Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Intelligent battery management Maximizes battery performance, life, and reliability through intelligent, precision charging.
Power conditioning Protects connected loads from surges, spikes, lightning, and other power disturbances.

Serviceability

Predictive failure notification Provides early-warning fault analysis ensuring proactive component replacement.
Hot-swappable batteries Ensure clean, uninterrupted power to protected equipment while batteries are being replaced
Battery failure notification Provides early-warning fault analysis on batteries enabling timely preventive maintenance
User-replaceable batteries Increase availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
Resettable circuit breakers Enable a quick recovery from overload events.

Adaptability

Adjustable voltage sensitivity Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.
Adjustable voltage-transfer points maximize useful battery life by widening the input voltage window or tightening the output voltage regulation.

Manageability

USB connectivity Provides management of the UPS via a USB port (not available on all models).
LED status indicators Quickly understand unit and power status with visual indicators.
Serial connectivity Provides management of the UPS via a serial port.
Audible alarms Actively let you know if the unit is on battery, if the battery is low, or if there is an overload condition.
Network manageable Provides remote power management of the UPS over the network.
Disconnected battery notification Warns when a battery is not available to provide backup power.

Serviceability

Battery failure notification Provides early-warning fault analysis on batteries enabling timely preventive maintenance
Resettable circuit breakers Enable a quick recovery from overload events.
Predictive failure notification Provides early-warning fault analysis ensuring proactive component replacement.
Hot-swappable batteries Ensure clean, uninterrupted power to protected equipment while batteries are being replaced
User-replaceable batteries Increase availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)

Adaptability

Adjustable voltage sensitivity Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.
Adjustable voltage-transfer points maximize useful battery life by widening the input voltage window or tightening the output voltage regulation.

Safety

Safety-agency approved Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.

Specifications:

Output

Max Configurable Power (Watts): 1.98kWatts / 2.2kVA
Output Voltage Note: Configurable for 220: 230 or 240 nominal output voltage
Output Voltage Distortion: Less than 5 % at full load
Output Frequency (sync to mains): 47 - 53 Hz For 50 Hz nominal Sync to mains, 57 - 63 Hz For 60 Hz nominal Sync to mains
Topology: Line interactive
Waveform type: Sine wave
Transfer Time: 6 ms typical: 10 ms maximum.

Input

Input frequency: 50/60 Hz +/- 3 Hz Auto-sensing.
Input voltage range for main operations: 151 - 302 Adjustable, 160 - 286V.
Number of Power Cords: 1
Other Input Voltages: 220 V, 240 V

Batteries & Runtime

Battery type: Lead-acid battery
Typical recharge time: 3hour(s)
Replacement Battery: RBC55
Expected Battery Life (years): 3 - 5
RBC Quantity: 1
Battery Charge Power (Watts): 260 Watts

Communications & Management

Interface Port(s): SmartSlot
Control panel: Multifunction LCD status and control console
Emergency Power Off (EPO): Yes
Available SmartSlot™ Interface Quantity

Surge Protection and Filtering

Surge energy rating: 365Joules
Filtering: Full-time multi-pole noise filtering: 0.3% IEEE surge let-through: zero clamping response time: meets UL 144

Physical

Maximum Height: 435MM, 43.5C
Maximum Width: 197MM, 19.7C
Maximum Depth: 544MM, 54.4C
Net Weight:48.8Kg
Shipping weight: 61.9Kg
Shipping Height: 699MM, 69.9CM
Shipping Width: 762MM, 76.2CM
Shipping Depth: 381MM, 38.1CM
Color: Black
Master Carton Dimensions (Length x Width x Height): 1200 x 800 x 830MM
Master Carton Units: 3.0
Master Carton Weight: 394.8
SCC Codes: 731304274025

Environmental

Operating Temperature: 0 - 40 °C
Operating Relative Humidity: 0 - 95 %
Operating Elevation: 0 - 3048meters
Storage Temperature: -15 - 45 °C
Storage Relative Humidity: 0 - 95 %
Storage Elevation: 0 - 15240meters
Audible noise at 1 meter from the surface of the unit: 45.0dBA
Online thermal dissipation: 275.0BTU/hr
Protection Class: IP20

Conformance

Approvals: CE, EAC, RCM, VDE
